PA Monofilament Extrusion Process Braided Fishing Line 0.08-4mm

Product Details

Place of Origin: CHANGZHOU,CHINA

Brand Name: LEAP

Certification: CE/ISO90001

Model Number: RS90

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: Negotiable

Packaging Details: Acceptable customization

Delivery Time: 30 working days

Payment Terms: L/C, T/T,

Supply Ability: 50 sets per year

Get Best Price
High Light:

0.08mm Monofilament Extrusion Process

,

PA Monofilament Extrusion Process

,

0.08mm PET monofilament extrusion line

Raw Material:
PA
Capacity:
80kgh
Application:
Braided Fishing Line Fishing Fly Wire
Diameter:
0.08-4mm
Power:
350kw
Screw Diameter:
90mm
L:D:
30:1
Characteristic:
High Strength
Raw Material:
PA
Capacity:
80kgh
Application:
Braided Fishing Line Fishing Fly Wire
Diameter:
0.08-4mm
Power:
350kw
Screw Diameter:
90mm
L:D:
30:1
Characteristic:
High Strength
PA Monofilament Extrusion Process Braided Fishing Line 0.08-4mm

PA Monofilament Extrusion Process for Braided Fishing Line Fishing Fly Wire 0.08-4mm



Product Description:



1. Extruder: 1 set

(1) Screw diameter: 80mm, Rotation speed of screw: 0~80 rpm.

(2) L:D: 30:1, Material of screw: 38CrMoALA ,

(3) Pressure automatic feedback system.

(4) Material of barrel heater: Cast aluminium with stainless steel insulation layer.

(5) Metering pump, rotation speed: 0-45 rpm.

(6) Round spinneret: 1 set.



2. Cooling water tank: 1 set



3. Seven roller stretching unit A

(1) Seven variable diameter rollers made by steel pipe with hard chrome plating.

(2) Steel box with accurately grind gear makes the rollers run smoothly.



4. Overflow type hot water tank: 1 set

(1) Tank size: 4000mm

(2) Water removal device: 2 sets with suction.



5. Seven roller stretching unit B

(1) Seven variable diameter rollers made by steel pipe with hard chrome plating.

(2) Equip 1 pressing roller.



6. Double layers hot blast stretching oven: 1 set

(1) Oven length: 4000 mm

(2) Heating power 23kw×2



7. Seven roller stretching unit C, with brake resistor

(1) Seven variable diameter rollers made by steel pipe with hard chrome plating.

(2) Equip 1 pressing roller.



8. Double layers hot blast stretching oven: 2 sets

(1) Oven length: 5000 mm

(2) Heating power 23kw×2



9. Seven roller stretching unit D.

(1) Seven variable diameter rollers made by steel pipe with hard chrome plating.

(2) Steel structure box with accurately grind gear makes the rollers run smoothly.



10. Lubricating system: 1 set

(1) Frequency control of speed



11. Spindle winder: 24 spindles

(1) Spool and bobbin are as sample.

(2) Winding motor: 15KG



Specification:

Screw diameter Φ90mm
Raw material Nylon Filament size 0.08-4mm
Capacity 80Kg/H Filament shape round
Screw L:D 30:1 Stretching unit 4 sets
Screw material 38CrMoALA Winder 12 spindles
Max linear speed 150m/min Instillation power 350Kw
Nozzle holes as requirement Overall size 50×2.8×2.8m




Picture:

PA Monofilament Extrusion Process Braided Fishing Line 0.08-4mm 0
