0.2mm Bristle Cleaning Brush Making Machine For Extra Hard Polypropylene
Key Attributes
Product Summary
Brush Making Machine For Extra Hard Polypropylene 0.2mm Industrial Bristle Product Description: 1. Extruder: 1 set 75mm; Rotation speed: 0～70rpm. (2) L:D: 33:1; screw material: 38CrMoALA ； (3) Pressure automatic feedback system to control screw speed. (6) Manual filter: 1 set (7) Spinneret ...
Product Details
0.2mm cleaning brush making machine
,Bristle cleaning brush making machine
,0.2mm brush manufacturing machine
Brush Making Machine For Extra Hard Polypropylene 0.2mm Industrial Bristle
Product Description:
1. Extruder: 1 set 75mm; Rotation speed: 0～70rpm.
(2) L:D: 33:1; screw material: 38CrMoALA ；
(3) Pressure automatic feedback system to control screw speed.
(6) Manual filter: 1 set
(7) Spinneret components: 2 sets
(8) Heating method: by Electric heater
2. Quenching tank: 1 set
(1) Tank is made by stainless steel.
(2) The height of tank is horizontal pushing structure.
3. The first seven roller stretching unit: 1 set
(1) Seven variable diameter rollers, material: steel pipe.
(2) Steel cabinet with accurately grind gear.
(4) Reducer is from Jiangsu Guomao.
4. Hot water tank: 1 set
(1) Tank length: 4000mm
(2) Heating power: 35kw, electric heating.
(3) The tank is made by SS 304.
5. The second seven roller stretching unit: 1 set
(1) Seven variable diameter rollers, material: steel pipe.
(2) Steel cabinet with accurately grind gear.
6. Hot Air oven: 1 set
(1) Fan power: 2.2KW×2 sets.
(2) Heating power: 23KW
(3) oven length: 4000mm.
7. Crimp unit: 1 set
(1) Equip two different rollers.
(2) Power: 4kw
8. The third seven roller stretching unit: 1 set
(1) Seven variable diameter rollers, material: steel pipe.
(2) Steel cabinet with accurately grind gear.
9. Lubricating system: 1 set
10. Winding machine: 2 spindles.
11. Independent Annealing oven: 1 set
(1) oven length: 6 meters
Parameter:
| Screw diameter | Φ65mm | ||
| Raw material | PP | Filament size | 0.2mm |
| Capacity | 40Kg/H | Filament shape | flat |
| Screw L:D | 33:1 | Stretching unit | 3 sets |
| Screw material | 38CrMoALA | Winder | 2 spindles |
| Max linear speed | 120m/min | Instillation power | 180Kw |
| Nozzle holes | 200 holes | Overall size | 36×2.4×2.7m |
