4" Polyester Filament Plastic Brush Making Machine Paint Brush Manufacturing Machine
Key Attributes
Product Summary
Brush Making Machine For Polyester Filament 4" Hollow Wall Paint Brush Product Description: 1. Extruder: 1 set (1) Screw dia.: 50mm; (2) L:D: 30:1; The screw is special design for PBT. (3) Reducer from Jiangyin Gearbox. (4) Pressure automatic feedback system. (5) Pressure sensor from Shanghai (6) ...
Product Details
4" plastic brush making machine
,Polyester plastic brush making machine
,Polyester paint brush manufacturing machine
Brush Making Machine For Polyester Filament 4" Hollow Wall Paint Brush
Product Description:
1. Extruder: 1 set
(1) Screw dia.: 50mm;
(2) L:D: 30:1; The screw is special design for PBT.
(3) Reducer from Jiangyin Gearbox.
(4) Pressure automatic feedback system.
(5) Pressure sensor from Shanghai
(6) 20cc Melt pump:1 set
(7) Motor of melt pump: 3.7kw
(8) Heater: Electric heating ring.
(9) Spinneret device: 1 Set
2. Quenching Tank:1 set
(1) Stainless Steel 304 tank
3. Seven roller Stretching unit A: 1 set
(1) Roller size: φ270×750×7,
(2) Power of motor: 7.5KW
(3) Steel cabinet with accurately grind gear.
(4) One pressing roller.
(5) The center height is 1100mm
4. Hot Water Tank:1 set
(1) Size (L×W×H) : 4000×800×1100 mm
(2) Heating power: 35KW;
(3) Water removal system: 4KW
5. Seven rollers stretching unit B: 0-160m
(1) Roller size: φ270×750×7,
(2) Power of motor: 15KW
(3) Steel cabinet with accurately grind gear.
(4) Reducer is from Zhejiang Tongli.
(5) The center height is 1100m
6. Hot Air oven: 3 sets
(1) Fan power: 2.2KW×2 sets.
(2) Heating power: 23KW
(3) Oven length: 4300 mm
7. Seven rollers stretching unit C: 1 set
(1) Roller size: φ270×750×7
(2) Power of motor: 15KW
(3) Steel cabinet with accurately grind gear.
(4) Reducer is from Zhejiang Tongli.
(5) One pressing roller.
(6) The center height is 1100m
8. Winding collector: 2 spindles
Specification:
| Screw diameter | Φ80mm | ||
| Raw material | Polyester | Filament size | 4" |
| Capacity | 80Kg/H | Filament shape | round |
| Screw L:D | 30:1 | Stretching unit | 3 sets |
| Screw material | 38CrMoALA | Winder | 2 spindles |
| Max linear speed | 80m/min | Instillation power | 350Kw |
| Nozzle holes | 400 holes | Overall size | 40×2.6×2.8m |
Picture:
