Cosmetic Brush Making Machine For PBT Virgin Makeup Artist Brush

Brush Making Machine For PBT Virgin Makeup Artist Cosmetic Brush

Product Description:

1. Extruder: 1 set

(1) Screw diameter: 45mm, Screw speed: 0～72 rpm.

(2) L:D: 30:1, Material of screw: 38CrMoALA with special treatment.

(3) Pressure automatic feedback system can control screw speed automatically.

(4) Melt pump 20cc, rotation speed: 0-45 rotation.

(5) Round spinneret: 1 set.

2. Quenching tank: 1 set

(1) Heating power:18KW.

3. Seven roller stretching unit A: 1 set

(1) Seven variable diameter rollers.

(2) Steel box with accurately grind gear makes the rollers run smoothly.

(3) Bearings: TIMKEN-TWB.

4. Hot water tank:1 set

(1) Tank size: 4000mm

(2) Heating power: 45KW in 2 zones

(3) The tank is made by SS 304 with insulating layer.

(4) Water circulating water pump 2 sets

5. Seven roller stretching unit B: 1 set

(1) Seven variable diameter rollers which made by steel pipe.

(2) Steel structure box with accurately grind gear.

(3) Bearings: TIMKEN-TWB.

6. Double layers hot blast stretching oven: 1 set

(1) Oven length: 4000 mm

(2) Special design of hot air channel.

7. Seven roller stretching unit C, with brake resistor

(1) Seven variable diameter rollers which made by steel pipes.

(2) Steel structure box with accurately grind gear.

(3) Bearings: TIMKEN-TWB.

8. Double layers hot blast stretching oven: 2 sets

(1) Oven length: 5000 mm

(2) Special design of hot air channel.

9. Seven roller stretching unit D: 1 set

(1) Seven variable diameter rollers which made by steel pipes.

(2) Steel structure box with accurately grind gear makes the rollers run smoothly.

(3) Bearings: TIMKEN-TWB.

10. Lubricating system: 1 set

(1) Frequency control of speed

11. Spindle winder: 2 spindles

12. Waster yarn collectors: 1 sets
