Product Details
Place of Origin: CHANGZHOU,CHINA
Brand Name: LEAP
Certification: CE/ISO90001
Model Number: RS
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Acceptable customization
Delivery Time: 90 working days
Payment Terms: L/C, T/T
Supply Ability: 50 sets per year
Material: |
PET |
Application: |
Forming Textile Belts |
Yarn Size: |
1mm |
Capacity: |
100kg/h |
Advantage: |
Acid And Alkali Resistance |
Technics: |
Uniform Air Permeability |
Screw L:D: |
30:1 |
Speed: |
100m/min |
Material: |
PET |
Application: |
Forming Textile Belts |
Yarn Size: |
1mm |
Capacity: |
100kg/h |
Advantage: |
Acid And Alkali Resistance |
Technics: |
Uniform Air Permeability |
Screw L:D: |
30:1 |
Speed: |
100m/min |
PET Monofilament Machine For Uniform Air Permeability Forming Textile Belts
Product Description:
1. Extruder: 1 set
(1) Screw diameter: 80mm,Screw: Zhejiang Zhoushan.
(2) L:D: 30:1, Material of screw: 38CrMoALA ,
The screw is suitable for PET chips and bottle flakes.
(3) Pressure automatic feedback system can adjust the screw speed automatically.
(4) Material of barrel heater: Cast aluminium.
(5) Metering pump 30cc, rotation speed: 0-45 rotation.
(6) Round spinneret: 1 set.
(7) Dosing unit: 1 set
2. Cooling water tank: 1 set
(1) The tank is made by SS 304.
(2) Using heating pipe, power:18KW.
(3) Equip one suction device under the yarn support plate.
3. Seven roller stretching unit A
(1) Seven variable diameter rollers which made by stainless steel 304.
(2) Steel box with accurately grind gear makes the rollers run smoothly.
(3) Built-out oil lubrication system.Bearings: TIMKEN-TWB.
(4) Equip water collecting plate at bottom.
4. Overflow type hot water tank:1 set
(1) Tank size: 4000mm
(2) Heating power: 45KW in 2 zones, Electric heating pipe is in the tank.
(3) The tank is made by SS 304 with insulating layer.
(4) Water removal device: 2 sets with 5.5kw fan.
(5) Water circulating water pump 2 sets
5. Seven roller stretching unit B
(1) Seven variable diameter rollers which made by steel pipe.
(2) Steel structure box with accurately grind gear makes the rollers run smoothly.
(3) Built-in oil lubrication system. Bearings: TIMKEN-TWB.
(4) Equip 1 pressing roller at exit.
6. Double layers hot blast stretching oven: 1 set
(1) Oven length: 4000 mm
(2) Special design of hot air channel.
7. Seven roller stretching unit C
(1) Seven variable diameter rollers which made by steel pipes.
(2) Steel structure box with accurately grind gear makes the rollers run smoothly.
(3) Built-in oil lubrication system. Bearings: TIMKEN-TWB.
(4) Equip 1 pressing roller at exit.
8. Double layers hot blast stretching oven: 2 sets
(1) Oven length: 5000 mm
(2) Special design of hot air channel.
9. Seven roller stretching unit D.
(1) Seven variable diameter rollers which made by steel pipes.
(2) Steel structure box with accurately grind gear makes the rollers run smoothly.
(3) Built-in oil lubrication system.
(4) Equip 1 pressing roller at exit.
10. Lubricating system: 1 set
(1) Frequency control of speed
(2) Material: All made by SS 304
11. Spindle winder:180 spindles
(1) Bobbin: /F7 (option).
(2) The frame transmission is frequency control, driving motor: 2.2kw
(3) The frame transmit by gear rack
12. Waster yarn collectors: 1 sets
13. Total installation power: 450KW
14. Total weight: 28T
| Screw diameter | Φ90mm | ||
| Raw material | PET | Filament size | 1mm |
| Capacity | 100Kg/H | Filament shape | profile |
| Screw L:D | 30:1 | Stretching unit | 3 sets |
| Screw material | 38CrMoALA | Winder | 180 spindles |
| Max linear speed | 100m/min | Instillation power | 400Kw |
| Nozzle holes | 20 holes | Overall size | 55×2.8×2.8m |
