Curved PP Monofilament Extrusion Line

Basic Information
Place of Origin: CHANGZHOU,CHINA
Brand Name: LEAP
Certification: CE/ISO90001
Model Number: RS120
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Acceptable customization
Delivery Time: 90 working days
Payment Terms: L/C, T/T,
Supply Ability: 50 sets per year
Detail Information
Density: 0.91g/cm3 Raw Material: PP
Elongation: 20+/-5% Application: Reinforced Macro Fiber
Name: Macro Fiber Color: Customized
Technics: Curved Package: Bundle
High Light:

Macro Fiber PP Monofilament Extrusion Line

,

Curved PP Monofilament Extrusion Line


Product Description

PP Monofilament Making Machine For Reinforced Macro Fiber Used In Concrete



Product Description:

1. Extruder: 1 set

(1) Screw diameter: 90 mm, Rotation speed of screw: 0~60 rpm.

(2) L:D: 33:1, Material of screw: 38CrMoALA; The screw is suitable for PP Virgin.

(3) Material of barrel heater: Cast aluminium.

(4) Electric heating round spinneret: 1 set

(5) Ceramic heating rings for spinneret with SS insulating layer make the heat evenly.

(6) Metering pump 100cc/rpm, rotation speed: 0-40 rotation.



2. Quenching tank: 1 set

(1) Material of distributing roller: stainless steel

(2) Side Push-pull model



3. Seven roller stretching unit A

(1) Seven roller variable diameter rollers, Five rubber roller.

(2) Steel box with accurately grind gear.

(3) Driving motor and reducer is from Zhejiang Tongli Reducer Co., Ltd.

(4) Built-out oil lubrication system which makes the gears runs steady.



4. Double layer hot blast stretching oven: 1 set

(1) Fan power: 2.2KW×4 sets

(2) Heating power: 23KW×2

(3) Oven length: 4000 mm

(4) Special design of hot air channel.



5. Seven roller stretching unit B.

(1) Seven roller variable diameter rollers, the working width 800mm.

(2) Steel box with accurately grind gear makes the rollers run smoothly.

(3) Driving motor and reducer is from Zhejiang Tongli Reducer Co., Ltd.



6. Single layers hot blast stretching oven: 1 set

(1) Fan power of each oven: 2.2KW×2 sets

(2) Heating power: 30KW

(3) Oven length: 5000mm

(4) Special design of hot air channel.



7. Seven roller stretching unit C.

(1) Seven roller variable diameter rollers, the working width 800mm.

(2) Steel box with accurately grind gear makes the rollers run smoothly.

(3) Driving motor and reducer is from Zhejiang Tongli Reducer Co., Ltd.



8. Waster yarn collectors: 1 set

(1) Torque motor power: 80KG.cm



9. Spool winder



11. Overall size: 40000×1800×2500mm





Specification:

Screw diameter Φ100mm
Raw material PP Filament size customzied
Capacity 150Kg/H Filament shape curved
Screw L:D 33:1 Stretching unit 3 sets
Screw material 38CrMoALA Instillation power 260Kw
Max linear speed 80m/min Overall size 37×2.7×2.8m




Pictures:

Curved PP Monofilament Extrusion Line 0
