Short Artificial Grass Yarn PP Monofilament Extrusion Line 250kgh

1. Extruder: 1 set

(1) Screw diameter: 70mm, there is thermometer hole in the barrel which has cooling fans.

(2) L:D: 33:1, Material of screw: 38CrMoALA ,

(3) Rotation speed of screw: 1～80 rpm.

(4) static mixer: 2 sets.

(5) Spinneret: 2 sets.

2. Cooling water tank

(1) The tank is made by SS 304 with one light and safety shield.

(2) Pushed and pulled in side way, the power driven lifting.

3. Five roller stretching unit A, 0-35m/min

(1) Motor power: 7.5kw

(2) The center height is 1200mm

4. Hot water tank

(1) Overall size: 4000×1300×1100 mm

(2) Heating method: electric heating

(3) Inside of the tank is made by SS 304 with insulating layer.

5. Oiling heating five roller stretching unit B, 0-160m/min

(1) 4 heating roller and working width 1300mm

(2) Standard heater has self-protective and alarm function.

Temperature control range: 70-120 degree.

(3) Driving motor and reducer: 15kw

7. Double layers hot blast stretching oven: 1 set

(1) Working area: 5000mm L×1350mm W.

Heating power: 35KW×2, the circulating fan: 4Kw×4.

(2) Frequency control speed of blast capacity. Temperature control range: 0-200 degree.

8. Three roller setting unit C, 0-160m/min

(1) Two cooling roller:φ318×1300×3,standard rotary joint.

(2) Driving motor and reducer: 7.5kw

9. Spindle winder: 64 spindles

(1) Constant tension magnetic disk deviation transmission.

(2) Winding motor: 250w, the bobbin size is according to the customer’s requirements.

10. Waster yarn collector

(1) Including pipes and fan, fan power: 7.5kw

11. The installation power: 330kw;

12. Overall size: 40000×2600×2000mm;

13. Total weight: 22T
