0.23mm Nylon Monofilament Extrusion Process White Protect Green Net
Key Attributes
Product Summary
Nylon Monofilament Extrusion Process For White Protect Green Net 0.23mm 50kgh Product Description: 1. Extruder: 1 set (1) Screw diameter: 80mm. (2) L:D: 30:1, Material of screw: 38CrMoALA , (3) Pressure feedback system. (4) Material of barrel heater: Far infarad (5) Metering pump 50cc, rotation ...
Product Details
0.23mm Monofilament Extrusion Process
,Nylon Monofilament Extrusion Process
,0.23mm PET monofilament yarn making machine
Nylon Monofilament Extrusion Process For White Protect Green Net 0.23mm 50kgh
Product Description:
1. Extruder: 1 set
(1) Screw diameter: 80mm.
(2) L:D: 30:1, Material of screw: 38CrMoALA ,
(3) Pressure feedback system.
(4) Material of barrel heater: Far infarad
(5) Metering pump 50cc, rotation speed: 0-45 rotation.
(6) Oil heating round spinneret: 1 set.
3. Quenching tank: 1 set
(1) The tank is made by SS 304.
4. First seven roller stretching unit
(1) Seven variable diameter rollers which made by stainless steel 304.
(2) Steel box with accurately grind gear.
(3) Built-out oil lubrication system which makes the gears runs steady
5. Overflow type hot water tank:1 set
(1) Tank size: 4000mm
(2) Heating power: 45KW in 2 zones,
(3) The tank is made by SS 304 with insulating layer.
(4) Water removal device: 2 sets with 5.5kw fan.
(5) Water circulating water pump.
6. Second seven roller stretching unit
(1) Seven variable diameter rollers which made by steel pipe.
(2) Steel structure box with accurately grind gear.
(3) Built-in oil lubrication system which makes the gears runs steady.
7. Double layers hot blast stretching oven: 1 set
(1) Oven length: 4300 mm
8. Third Seven roller stretching unit
(1) Seven variable diameter rollers which made by steel pipes.
(2) Steel structure box with accurately grind gear.
(3) Built-in oil lubrication system which makes the gears runs steady.
9. Double layers hot blast stretching oven: 2 sets
(1) Oven length: 4300 mm
10. Forth Seven roller stretching unit
(1) Seven variable diameter rollers which made by steel pipes.
(2) Steel structure box with accurately grind gear.
(4) Built-in oil lubrication system which makes the gears runs steady.
11. Lubricating system: 1 set
(1) Frequency control of speed
12. Spindle winder: 312 spindles
(1) Spool and bobbin are as client's reqeust
(2) The frame transmission is frequency control, driving motor: 2.2kw
(3) Winding motor: 5KG
13. Waster yarn collectors: 2 sets
Parameter:
| Screw diameter | Φ70mm | ||
| Raw material | Nylon | Filament size | 0.23mm |
| Capacity | 50Kg/H | Filament shape | round |
| Screw L:D | 30:1 | Stretching unit | 4 sets |
| Screw material | 38CrMoALA | Winder | 252 spindles |
| Max linear speed | 160m/min | Instillation power | 330Kw |
| Nozzle holes | 240 holes | Overall size | 50×2.9×2.9m |
