4800 Dtex PP Monofilament Extrusion Line
Key Attributes
Product Summary
PP Artificial Grass Extruder For Playground Anti-UV Curly Hybrid Turf 4800 Dtex Product Description: 1. 75×33 Extruder:2 sets (1) Main motor power: 37KW; (2) Screw diameter: 70mm; (3) L:D: 33:1; Material of screw: 38CrMoALA (4) Rotation speed of screw: 0～90rpm (5) Reducer: Jiangyin Gearbox ...
Product Details
Artificial Grass monofilament extrusion line
,4800 Dtex PP monofilament extrusion line
PP Artificial Grass Extruder For Playground Anti-UV Curly Hybrid Turf 4800 Dtex
Product Description:
1. 75×33 Extruder:2 sets
(1) Main motor power: 37KW;
(2) Screw diameter: 70mm;
(3) L:D: 33:1; Material of screw: 38CrMoALA
(4) Rotation speed of screw: 0～90rpm
(5) Reducer: Jiangyin Gearbox manufacturer.
(6) Pressure automatic feedback system can adjust the screw speed automatically.
(7) Far infarad heating rings.
(8) Metering pump:2 sets
Spinneret: 1 set, components: 2 sets
(9) Static mixer: 1 set
(10) Filter changer: 1 set
2. Cooling water tank: 1 set
(1) The tank is made by stainless steel 304.
(2) The horizontal pushing structure is conveniently to disassembly the spinneret.
3. Seven roller stretching unit A: 1 Set
(1) Steel roller size: φ270×700×7
The 7 rollers are made by SS 304 with hard chrome plating.
(2) Steel structure cabinet with gear transmission,no pressure rollers.
(4) The frame is covered with stainless steel 304 plate to prevent the water.
4. Hot water tank: 1 set
(1) Tank length:4000mm
(2) The water is heated by copper heating pipe, the heating power: 50kw,
(3) The tank is made by SS 304.
5. Water removal system with moisture absorption: 1 set
(1) Fan power:4kw×1 set
6. Seven roller stretching unit B: 1 Set
(1) Steel roller size: φ350×700×7.
The 7 rollers are made by SS 304 with hard chrome plating.
(2) The stretching unit is covered with stainless steel 304 plate to prevent the water.
7. Waster yarn collector system: 1 set
(1) Motor power: 7.5KW
8. Air texturing machines: 24 ends
Specification for each end:
(1) Gas heating barrel:1 sets
(2) Main conveying pipe:1 set,
Each pipe has control valve
(3) Heating roller and drive: 2 sets. The roller is heated by electric and temperature control independently.
(4) Tension roller: 2 sets, aluminum oxide processing
(5) Nozzle:1set
9. Conveyer device: 3 sets+1 piece
(1) 1 set includes 4 working position.
(2) Length of conveyer belt is 4000mm.
10. Automatic tension feedback winder: 24 spindles
(1) Motor of tension roller:0.5kw
(2) Bobbin size based on customer’s requirements.
Parameter:
| Screw diameter | Φ75mm | ||
| Raw material | PP | Filament size | 4800 Dtex |
| Capacity | 150Kg/H | Filament shape | Curly |
| Screw L:D | 33:1 | Stretching unit | 2 sets |
| Screw material | 38CrMoALA | Winder | 24 spindles |
| Max linear speed | 250m/min | Instillation power | 450Kw |
| Nozzle holes | 300 holes | Overall size | 45×2.8×2.8m |
Pictures:
