Highlight:
                                                                                                                                                                                                                                                                                                                Djembe Rope monofilament extrusion plant, 0.35mm monofilament extrusion plant, 0.35mm monofilament extruder


Material:	Polyester	Yarn Diameter:	0.35mm
Capacity:	120kgh	Application:	Djembe Rope
Pattern:	Braided Cord	Rope Diameter:	3mm
Winder:	56 Spindles	Voltage:	Customized

Material:	Polyester
Yarn Diameter:	0.35mm
Capacity:	120kgh
Application:	Djembe Rope
Pattern:	Braided Cord
Rope Diameter:	3mm
Winder:	56 Spindles
Voltage:	Customized

0.35mm Monofilament Extrusion Plant 3mm Polyester Braided Djembe Rope

Monofilament Yarn Machine For Polyester Braided Cord 3mm Djembe Rope 0.35mm

Product Description:

1. Extruder: 1 set

(1) Screw diameter.: 90mm; Rotation speed of screw: 0～72rpm,

(2) L:D: 30:1; screw material: 38CrMoALA;

(3) Pressure automatic feedback system.

(4) Melt filter: Double position melt filter changer, candle fitler

(5) Spinneret device: 1 set

(6) Metering pump: 1set

(7) Heated by electric heating ring

2. Queching Tank:1 set

(1) The tank is made by Stainless Steel.

(2) The height of tank is adjustable.

3. Seven roller Stretching unit A: 1 set

(1) Seven pieces variable diameter roller.

(2) Steel cabinet with accurately grind gear.

4. Hot water Tank:1 set

(1) Heating power: 50KW; Electrical heating pipe into water.

(2) Material is stainless steel 304.

5. Seven rollers stretching unit B: 1 set

(1) Seven pieces variable diameter roller with hard chrome plating.

(2) Steel cabinet with accurately grind gear.

6. Spindle winder: 56 spindles

(1) Winding spool as customer's requirement.

Parameter:

Screw diameter	Φ85mm
Raw material	Polyester	Filament size	0.35mm
Capacity	120Kg/H	Filament shape	Profile
Screw L:D	30:1	Stretching unit	2 sets
Screw material	38CrMoALA	Winder	56 spindles
Max linear speed	120m/min	Instillation power	250Kw
Nozzle holes	400 holes	Overall size	36×2.6×2.8m
