4 Strand PET Plastic Rope Making Machine For High Strength Twisted Rope
Key Attributes
Product Summary
Rope Making Machine For High Strength 4 Strand Twist PET Rope Product Description: 1. Extruder: 1 set (1) Screw dia.: 85mm; Rotation speed: 0～80rpm, (2) L:D: 30:1; The screw is special design for PET recylce material. (3) Pressure feedback system can adjust the screw speed automatically. (4) Melt ...
Product Details
4 Strand plastic rope making machine
,PET plastic rope making machine
,4 Strand rope twisting machine
Rope Making Machine For High Strength 4 Strand Twist PET Rope
Product Description:
1. Extruder: 1 set
(1) Screw dia.: 85mm; Rotation speed: 0～80rpm,
(2) L:D: 30:1; The screw is special design for PET recylce material.
(3) Pressure feedback system can adjust the screw speed automatically.
(4) Melt filter: Melt filter changer with candles
(5) Spinneret device: 1 set
(6) Metering pump: 1 set
(7) Color doserm: 1 set
(8) Magnet device: 1 set
2. Quenching Tank:1 set
(1) The tank is made by Stainless Steel 304.
(2) The horizontal pushing structure is conveniently to disassembly the spinneret.
3. First Seven roller Stretching unit: 1 set
(1) Seven pieces variable diameter roller with hard chrome plating.
(2) Built-out oil lubrication system makes gears run steady.
4. Hot water Tank:1 set
(1) Heating power: 70KW; Electrical heating, copper heating pipe
(2) Equip two pressing roller .
5. Second seven rollers stretching unit
(1) Seven pieces variable diameter roller with hard chrome plating.
(2) Built-in oil lubrication system which makes the gears run steady.
6. Spindle winder
(1) Tapered winder
(2) Winding bobbin as per clinet's reqeust.
(3) Tesnion control by inverter.
Parameter:
| Screw diameter | Φ90mm | ||
| Raw material | PET | Filament size | 0.35mm |
| Capacity | 100Kg/H | Filament shape | round |
| Screw L:D | 30:1 | Stretching unit | 2 sets |
| Screw material | 38CrMoALA | Winder | 33 spindles |
| Max linear speed | 120m/min | Instillation power | 130Kw |
| Nozzle holes | 400 holes | Overall size | 28×2.6×2.6m |
Pictures:
