Polyester PP Rope Making Machine For 3 Strand 6mm Twisted Rope
Key Attributes
Product Summary
Rope Making Machine For 3-Strand 6mm Twisted PP Polyester Mixed Rope Product Description: 1. Extruder: 1 set (1) Screw dia.: 85mm; Rotation speed: 0～80rpm, (2) L:D: 30:1; The screw is special design for PET recylce material. (3) Spinneret device: 1 set (4) Metering pump: 1 set (5) Magnet device: 1 ...
Product Details
6mm pp rope making machine
,Polyester pp rope making machine
,3 Strand pp rope machine
Rope Making Machine For 3-Strand 6mm Twisted PP Polyester Mixed Rope
Product Description:
1. Extruder: 1 set
(1) Screw dia.: 85mm; Rotation speed: 0～80rpm,
(2) L:D: 30:1; The screw is special design for PET recylce material.
(3) Spinneret device: 1 set
(4) Metering pump: 1 set
(5) Magnet device: 1 set
2. Quenching Tank:1 set
(1) The horizontal pushing structure is conveniently to disassembly the spinneret.
3. First Seven roller Stretching unit: 1 set
(1) Seven pieces variable diameter roller.
(2) Built-out oil lubrication system makes gears run steady.
4. Hot water Tank:1 set
(1) Heating power: 70KW; Electrical heating, copper heating pipe
(2) Equip two pressing roller .
5. Second seven rollers stretching unit: 1 set
(1) Seven pieces variable diameter roller.
(2) Built-in oil lubrication system which makes the gears run steady.
6. Spindle winder
(1) Tesnion control by inverter.
Parameter:
| Screw diameter | Φ100mm | ||
| Raw material | PET PP | Filament size | 0.4mm |
| Capacity | 150Kg/H | Filament shape | round |
| Screw L:D | 30:1 | Stretching unit | 2 sets |
| Screw material | 38CrMoALA | Winder | 48 spindles |
| Max linear speed | 100m/min | Instillation power | 250Kw |
| Nozzle holes | 300 holes | Overall size | 29×2.6×2.6m |
Pictures:
